DG32-LITE puts a hardware lockstep safety monitor, the motor-drive peripherals and the FOC maths in one 64-pin chip. DG32-2DOM is the same chip with an attention engine on its own clock, so a board built for one takes the other.
WHY A SECOND CORE
Motor control drives power electronics, and a silent CPU fault can destroy a bridge. Hardware lockstep has lived in automotive MCUs such as Infineon AURIX, NXP S32K and TI Hercules; DG32-LITE brings it to the entry-level motor-control tier.
| Question | Software self-test | DG32 hardware lockstep |
|---|---|---|
| When it checks | Periodically, when the test is scheduled | On every committed store |
| Between checks | Blind: a fault can act before the next run | No gap: CHECKER runs two cycles behind |
| Who stops the bridge | Firmware, once it notices | FAULT_N, in hardware, without waiting for firmware |
A transient or permanent error changes a value the MAIN core is about to commit.
CHECKER runs the same instructions two cycles later on mirrored inputs and bus responses, so it commits the correct value.
Every committed store is compared. The first mismatch is caught on that store, not at the next software self-test.
A sticky fault latch holds the first cause, because later faults are usually its consequences. Firmware can read it after the fact.
FAULT_N goes low within 39 cycles of an injected fault in simulation. Wired to the gate-driver enable, it stops the bridge without waiting for firmware.
The 39-cycle figure is measured in simulation, from an injected fault to the latch.
WHAT IS IN THE CHIP
Choose a block to see what it does and why it is there. Then switch to DG32-2DOM: the six groups are the same design from the same source, and only the attention engine and its bridges are new.
50 MHz control domain
SAFE
WhyMotor control drives power electronics. A silent CPU fault can destroy a bridge; a second core that must agree bit-for-bit turns that fault into an observable signal.
Open the full DG32-LITE diagram| Area | DG32-LITE | DG32-2DOM |
|---|---|---|
| Control core | Two RV32IM cores in hardware lockstep | Identical, frozen and unchanged |
| Boot and memory | 64 KB boot ROM, 32 KB dual-port SRAM, external QSPI flash | Identical |
| Motor and sensing | PWM with brake, 4 × DShot, encoder and Hall, SAR ADC, CORDIC | Identical |
| Connectivity | 2 × UART, SPI, I²C, GPIO, JTAG and scan | Identical |
| Control-loop budget | ~300 hardware cycles per loop; ~100 kHz simulated ceiling | Identical; the engine cannot extend it |
| Clocks | One 50 MHz domain | 50 MHz control domain plus a 114 MHz compute domain |
| On-chip compute | None | INT8 attention engine, bit-exact to the software model |
| Package and pinout | QFN-64, 9 × 9 mm, 44 signal pins | Identical; the engine adds no pads |
| Supplies | 1.8 V core, 3.3 V I/O | Identical |
| Power estimate | ~0.43 W at 50 MHz (tool estimate) | Same figure stated; no separate engine figure yet |
| Die | 2.9 × 4.5 mm core block | Its own 3.4 × 4.5 mm die |
| Status | First silicon, September 2026 shuttle | Design complete, in physical trials |
First silicon · September 2026 multi-project shuttle
Design complete · in physical trials
Pre-silicon. Figures are design values verified in simulation and static timing, not measurements on fabricated parts, unless marked otherwise. The ~0.43 W power figure is a vectorless tool estimate at 25 °C and 1.8 V.
WILL IT RUN YOUR LOOP
Sampling, the Park transforms and the PWM update are dedicated blocks costing about 300 cycles at any loop rate; the CPU keeps only the two PI regulators. What is left at each rate is the firmware budget.
Cycle costs measured in simulation at the 50 MHz clock; 100 kHz is the simulated ceiling, not a bench result.
WHERE DG32 SITS
Sub-10 nm silicon cannot withstand 28 V to 120 V transient rails, carries no 24-bit high-dynamic-range analog front end, and does not survive automotive and military screening from −55 °C to +125 °C without external support. DeepGrid anchors those physical interfaces on 130 nm and 180 nm, taking the satellite sockets around the sub-10 nm central compute rather than competing with it. DG32 is SKU-4 of that portfolio, the lockstep safety MCU.
| SKU | Part | Node |
|---|---|---|
| SKU-1 | BLDC Motor Controller | 130 nm BCD |
| SKU-2 | Smart-Meter SoC | 130 nm CMOS |
| SKU-3 | High-Reliability PMIC | 180 nm BCD |
| SKU-4 | DG32-LITE | 130 nm CMOS |
| SKU-4 variant | DG32-2DOM | 130 nm CMOS |
| SKU-5 | Robust Transceiver | 130 nm HV |
| SKU-6 | Voltage Supervisor | 180 nm CMOS |
| SKU-7 | DG-RADAR-77 | 0.13 µm SiGe BiCMOS |
| SKU-8 | DG-DISP-17 | 130 nm HV CMOS |
| SKU-9 | DG-SDV-ZONE | 130 nm + 180 nm |
| Track B | DG-D100 | 130 nm + 28 nm, multi-die SiP |
Portfolio, numbering and nodes reconciled on 23 September 2026 against the SKU Architecture Compendium (Technical Annex v3) and the Mature-Node Silicon System Architecture, which agree chip for chip. Phase names the sovereignty foundry, not a date: Phase 1 SkyWater, Phase 2 IHP, Phase 3 SCL Mohali. Anchor customers and contract values are held off this table pending verification.
WHICH CHIP FOR YOUR DRIVE
For a drive that needs hardware lockstep safety, hardware FOC acceleration and native DShot in a 64-pin part.
WHYIt is the first-silicon part: on the September 2026 shuttle, with bring-up measuring the loop costs, fault latency and timing it was designed to.
For a drive that should also watch its own motor: bearing-fault or anomaly detection on phase-current data, without a second processor.
WHYThe engine runs on its own clock behind bridges, so condition monitoring cannot extend the control core’s worst-case execution time. Design complete, in physical trials.
