The far horizon

SoC4-A is optionality this raise does not fund, not a commitment.

SoC4-A is a far-horizon chip, 1,024 tiles on a 4 nm process, assembled from published open PULP silicon IP, targeting a Q3 2029 tape-out and packaged into a four-chip, 4U rack-mount box called MicroDC-A1. It sits deliberately outside the current plan: SoC2 is the funded business; SoC4-A is the option that business buys investors.

  • 16.76 PFLOPS FP4Peak per chassis
  • ~12 PFLOPS FP4Sustained (projected)
  • 4,096 tiles total4 chips × 1,024
  • Q3 2029Tape-out target
  • 1,120 WPower envelope
  • 256 GB LPDDR5XDRAM per chassis
The far horizon SoC4-A, a 1,024-tile mesh the raise does not fund · 0:57
  1. SoC4-A sits outside the roadmap just presented, introduced here as a separate horizon. It shows investors what the current business is ultimately building toward.

  2. The design places 1024 tiles in a 32x32 mesh on TSMC's 4nm process, targeting 4 petaflops at FP4. These are design parameters shown through animation, not measured silicon.

  3. An animated diagonal wavefront moves across the full grid, illustrating a store propagating from one edge to the other. Moving data efficiently at this scale is the central engineering challenge the mesh must solve.

  4. Each tile is a 5-port router with a safety wrapper, and its internal blocks come from the open PULP platform. FlooNoC, Spatz, ITA, and IDMA are all published, silicon-proven designs, not original sketches.

  5. SoC4-A does not raise the current round; SoC2 is the product that does. The mesh is the long-term option that a successful SoC2 business makes possible.

Rendering of the MicroDC-A1, a 4U 19-inch rack unit holding four SoC4-A modulesInspect full-size figure ↗
MicroDC-A1: a conceptual 4U rack-mount serverA conceptual rendering of the DGRID MicroDC-A1, a 4U 19-inch rack-mount chassis housing four SoC4-A processor modules with cold-plate liquid cooling, network interfaces, and status indicators on the front panel.The MicroDC-A1 is a roadmap option, with SoC4-A silicon targeting a Q3 2029 tape-out and chassis shipments in 2030 and beyond; it packages four SoC4-A chips for 16.76 PFLOPS FP4 peak per chassis and sits outside the current raise.Rendering from the Information Memorandum: a conceptual product, not hardware that exists
Technical detail

The MicroDC-A1 is a conceptual product: one 4U, 19-inch rack-mount chassis housing four SoC4-A chips, each carrying 1,024 tiles on a 4 nm process and drawing 280 W under cold-plate dielectric (3M Novec) cooling. Peak compute is 16.76 PFLOPS FP4 dense (4 chips × 4.19 PFLOPS); sustained throughput is projected at approximately 12 PFLOPS FP4, pending validation in the SoftHier simulator, all numbers are provisional pending first silicon. Memory totals 256 GB LPDDR5X-9600 across the chassis, with an aggregate bandwidth design target of approximately 1.84 TB/s, and network connectivity of 2× 400 GbE plus 2× 100 GbE. The Information Memorandum describes use cases including sovereign-AI inference (the ~12 PFLOPS sustained figure is cited as sufficient for approximately 50 concurrent users on a 70B-parameter LLM, or approximately 200 users on a 13B model), robotaxi fleet compute, and telecom edge inference, all described as conceptual. SoC4-A silicon targets a Q3 2029 tape-out; MicroDC-A1 chassis shipment is indicated as 2030 or later.

Portfolio deck, slide 103: SoC4-AInformation Memorandum v2 (Aug 2026), page 17: Roadmap: SoC4-A, FY30 and later
